braindecode.models.EEGNetv4#

class braindecode.models.EEGNetv4(n_chans=None, n_outputs=None, n_times=None, final_conv_length='auto', pool_mode='mean', F1=8, D=2, F2=16, kernel_length=64, third_kernel_size=(8, 4), drop_prob=0.25, chs_info=None, input_window_seconds=None, sfreq=None, in_chans=None, n_classes=None, input_window_samples=None)[source]#

EEGNet v4 model from Lawhern et al 2018.

See details in [EEGNet4].

Parameters:

  • n_chans (int) – Number of EEG channels.

  • n_outputs (int) – Number of outputs of the model. This is the number of classes in the case of classification.

  • n_times (int) – Number of time samples of the input window.

  • final_conv_length (int | "auto") – If int, final length of convolutional filters.

  • pool_mode – The description is missing.

  • F1 – The description is missing.

  • D – The description is missing.

  • F2 – The description is missing.

  • kernel_length – The description is missing.

  • third_kernel_size – The description is missing.

  • drop_prob – The description is missing.

  • chs_info (list of dict) – Information about each individual EEG channel. This should be filled with info["chs"]. Refer to mne.Info for more details.

  • input_window_seconds (float) – Length of the input window in seconds.

  • sfreq (float) – Sampling frequency of the EEG recordings.

  • in_chans – Alias for n_chans.

  • n_classes – Alias for n_outputs.

  • input_window_samples – Alias for n_times.

Raises:

  • ValueError – If some input signal-related parameters are not specified: and can not be inferred.

  • FutureWarning – If add_log_softmax is True, since LogSoftmax final layer: will be removed in the future.

Notes

This implementation is not guaranteed to be correct, has not been checked by original authors, only reimplemented from the paper description.

References

[EEGNet4]

Lawhern, V. J., Solon, A. J., Waytowich, N. R., Gordon, S. M., Hung, C. P., & Lance, B. J. (2018). EEGNet: A Compact Convolutional Network for EEG-based Brain-Computer Interfaces. arXiv preprint arXiv:1611.08024.
